Pump P-903
Pump P-903
| Accuracy | ±2% or 2 μl/min whichever is greater, with compression compensation activated (0.2–25.0 MPa) |
| Analog Output | Pressure, 0 to 1V |
| Chemical stability | The wetted parts are resistant to organic solvents and salt buffers commonly used in chromatography of biomolecules, except 100% Ethylacetate, 100% Hexane, and 100 % Tetrahydrofuran (THF). |
| Compliance | The product fulfills valid directives and standards when used within the conditions specified in the user manual. The product must also be used in the same state as it was delivered from Cytiva and connected only to other CE labeled Cytiva modules or other products as recommended. For regulatory details please see declaration of conformity. |
| Connections | UNF 10-32 2B ”Fingertights” |
| Depth | 370 mm |
| Flow rate | 0.001-10 ml/min |
| Height | 150 mm |
| Includes | Pump with 4 pump heads, inlet filter assembly, inlet tubing kit [1/82], tubing kit for rinsing system, mixer M-925, mixer chamber [2.0 ml with pump P-901 and 0.6 ml with pump P-903], mixer bracket, PEEK tubing [2 m, 0.5 mm i.d., 1/162 o.d.), fingertight connector [1/162], injection syringe 30 ml, stop plug [1/162] and a signal cable |
| Material | Polyetheretherketone (PEEK) Polytetrafluoroethylene (PTFE) Ethylenechlorotrifluoro-ethylene (ECTFE) Polyvinylidenefluoride (PVDF) Polyethylene (PE) Titanium alloy (Ti alloy) Aluminium oxide (Al oxide) Elgiloy Ruby Zirconia |
| Operating pressure max. | 250 bar (25 MPa) (3625 psi) |
| Operating Temperature | 4°C-40°C |
| pH Stability Long Term | 1-13 |
| pH Stability Short Term | 1–14 |
| Power consumption | Max. 400 VA with all extra components connected |
| Protection class | IP 20 (Housing) |
| Relative humidity | 20%-95% (non condensing) |
| Viscosity Max. | 5 cP |
| Voltage | 100-120/220-240 VAC |
| Weight | 17 kg |
| Wetted Materials | Polyetheretherketone (PEEK) Polytetrafluoroethylene (PTFE) Ethylenechlorotrifluoro-ethylene (ECTFE) Polyvinylidenefluoride(PVDF) Polyethylene (PE) Titanium alloy (Ti alloy) Aluminium oxide (Al oxide) Elgiloy Ruby Zirconia |
| Wetted Part | Yes |
| Width | 260 mm |
